For models: Gorton 8D, 8-1/2D, 9J Vertical Milling Machines
                Gorton 8D, 8-1/2D, 9J Duplicators
                Gorton 8D Universal Milling Machine

Description: This is an Operators Manual for the Gorton Vertical & Duplicating Milling Machines Models 8D, 8 1/2D, & 9J, and also the 8D Universal Milling Machine.  It contains sections on Operation, Lubrication,   Adjustments, Die Mold Cutting, Models for Die and Mold Duplicating, Cutters for Die and Mold Work, Grinding Single Flutes, Cutters with Gorton Cutter Grinders, and a Cutter Speed Chart.  It has a complete set of cutaway parts views and part numbers.  The manual has 28 pages.   To inspect the quality of the manual,  and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Unpacking and Erecting
• Lubrication
• Adjustments
• Operation
• Die & Mold Cutting
• Models for Die & Mold Cutting
• Cutters for Die and mold Cutting
• Grinding Single Flutes
• Cutters with Gorton Cutter Grinders
• Cutter Speed Chart

• Assembly Drawings with Part Numbers


Number of pages: Approx 28
Publication date: N/A
Publication No.: 1410

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Added Notes:   Due to others making copies of these manuals for resale, I have lightly watermarked select pages to discourage this practice.
