Thermal Dynamics Pak Master 100XL Plasma Cutter

Service  Manual

For models: PakMaster 100XL
Description: This is a Service Manual for the model Pak Master100XL  plasma cutter. It has instructions on test procedures, troubleshooting flow charts, wiring diagrams, repair and replacement procedures, and parts breakdown. The manual has 76 pages.  To inspect the quality of the manual, view the table of contents, and to view select pages,  please click on the gallery images above to enlarge.

Note: This manual does not  cover the  torch.

Includes sections on:

• Servicing
• Test Procedures

• Troubleshooting Flow Charts
• Repair and Replacement Procedures

• Parts Lists
• Wiring Diagrams
• Theory of Operation


Number of pages: Approx 76
Condition: Very Good
Publication date: December 2000
Publication No.:  0-2582
